Category |
Grinders - Cylindrical |
|||
Manufacturer |
Waldrich Seigen |
|||
Model |
WST IV H80 x 12000 |
|||
Serial Number |
12547 |
|||
Year |
1981 / Installed 1982 |
|||
Maximum Grinding Diameter |
78.00 |
in |
1981.20 |
mm |
Distance Between Centers |
472.40 |
in |
12000.00 |
mm |
Maximum Workpiece Weight |
176000.00 |
lbs |
80000.00 |
kg |
Wheel Width Maximum |
4.00 |
in |
100.00 |
mm |
Wheel OD Diameter |
32.00 |
in |
812.80 |
mm |
Wheel ID |
12.00 |
in |
305.00 |
mm |
Wheelhead Angle |
90 Degrees To Workpiece Axis |
|||
Wheel Spindle Power |
27 - 59/59 |
HP |
20 - 44/44 |
kW |
Wheel Spindle Speed |
450 - 1800 RPM Infinitely Variable |
|||
Wheel Dresser |
Bed Mounted Roll |
|||
Wheelhead Cross Travel |
25.60 |
in |
650.00 |
mm |
Wheelhead Longitudinal Travel |
488.40 inch, 12405 mm |
|||
Wheelhead Speed |
157.5 inches/min, 4000 mm/min |
|||
Workhead Power |
1.9 - 59/59 |
HP |
1.4 - 44/44 |
kW |
Workhead Speed |
.5 - 300 RPM |
|||
Sludge Conveyor |
None |
|||
Coolant |
Yes |
|||
Filtration System |
Combination 2 Cartridge And Fabric Filter |
|||
Ways |
Cast Iron Full Hydrostatic |
|||
Way Covers |
Metal Telescopic |
|||
Power |
Existing |
|||
Additional |
Waldrich Siegen 4 in (100 mm) width roll belt grinding attachment, roll cambering / crowning, range of table setting for camber / convex: .0005 - .292 mm, range of table setting for camber / convex / and concave .0004 - .1024 mm, range of table setting for camber based on radius: .0039 - .1496, 2 - 2 jaw steady rests: diameter range 7.88 - 20 in (200 - 510 mm), cross adjustment of steady rests: 23.6 in (600 mm) |
|||
Machine Length |
732.00 |
in |
18600.00 |
mm |
Machine Width |
219.00 |
in |
5570.00 |
mm |
Machine Height |
91.00 |
in |
2320.00 |
mm |
Weight |
134000.00 |
lbs |
60800.00 |
kg |
Condition |
Excellent |
